ui中和easy ui中的很像,但是最近用到的時候全然沒有印象,一段時間不用就忘記了,這篇隨筆介紹一下這個控件。
1.實例
官網源代碼中給出了一些實例,首先看看實例是什么樣子的。
a.默認功能
也是最簡單的應用,也就是打開一個對話框,代碼如下
doctype html>
<html lang="en">
<head>
<meta charset="utf-8">
<title>jQuery UI Dialog - Default functionalitytitle>
<link rel="stylesheet" href="../../themes/base/all.css">
<script src="../../external/jquery/jquery.js">script>
<script src="../../ui/core.js">script>
<script src="../../ui/widget.js">script>
<script src="../../ui/mouse.js">script>
<script src="../../ui/draggable.js">script>
<script src="../../ui/position.js">script>
<script src="../../ui/resizable.js">script>
<script src="../../ui/button.js">script>
<script src="../../ui/dialog.js">script>
<link rel="stylesheet" href="../demos.css">
<script>
$(function() {
$( "#dialog" ).dialog();
});
script>
head>
<body>
<div id="dialog" title="Basic dialog">
<p>This is the default dialog which is useful for displaying information. The dialog window can be moved, resized and closed with the 'x' icon.p>
div>
<div class="demo-description">
<p>The basic dialog window is an overlay positioned within the viewport and is protected from page content (like select elements) shining through with an iframe. It has a title bar and a content area, and can be moved, resized and closed with the 'x' icon by default.p>
div>
body>
html>
引用了一堆的js文件,這個與下載的時候選擇的類型有關模態對話框是什么時候實例的對話框,可以選擇All UI ,也可以在當前頁面選擇要用到的組件下載。關鍵代碼$( "#" ).();,加載頁面的時候彈出一個對話框。效果如下圖1
圖1
b.模態對話框
關鍵代碼如下:
$(function() {
$( "#dialog-message" ).dialog({
modal: true,
buttons: {
Ok: function() {
$( this ).dialog( "close" );
}
}
});
});
作用是彈出一個模態對話框,mode:true,其實就是后面不能回到后面的父頁面,除非關閉當前的對話框。在對話框后面加了一個OK關閉按鈕,效果如下圖2
圖2
c.確認對話框
關鍵代碼如下:
$(function() {
$( "#dialog-confirm" ).dialog({
resizable: false,
height: "auto",
width: 400,
modal: true,
buttons: {
"Delete all items": function() {
//這里可以加入一些操作 $( this ).dialog( "close" );
},
Cancel: function() {
$( this ).dialog( "close" );
}
}
});
});
加了兩個按鈕,一個確認,一個取消,可以分別做一些操作,其實也不限于這兩個按鈕,如果需要的話可以在下面添加任意多個按鈕,實現任意多的功能。效果如下如3
圖3
帶form功能的對話框
這個例子有些復雜,可以實現驗證,請求等功能,關鍵代碼如下
doctype html>
<html lang="en">
<head>
<meta charset="utf-8">
<title>jQuery UI Dialog - Modal formtitle>
<link rel="stylesheet" href="../../themes/base/all.css">
<script src="../../external/jquery/jquery.js">script>
<script src="../../ui/core.js">script>
<script src="../../ui/widget.js">script>
<script src="../../ui/mouse.js">script>
<script src="../../ui/button.js">script>
<script src="../../ui/draggable.js">script>
<script src="../../ui/position.js">script>
<script src="../../ui/resizable.js">script>
<script src="../../ui/dialog.js">script>
<script src="../../ui/effect.js">script>
<link rel="stylesheet" href="../demos.css">
<style>
label, input { display:block; }
input.text { margin-bottom:12px; width:95%; padding: .4em; }
fieldset { padding:0; border:0; margin-top:25px; }
h1 { font-size: 1.2em; margin: .6em 0; }
div#users-contain { width: 350px; margin: 20px 0; }
div#users-contain table { margin: 1em 0; border-collapse: collapse; width: 100%; }
div#users-contain table td, div#users-contain table th { border: 1px solid #eee; padding: .6em 10px; text-align: left; }
.ui-dialog .ui-state-error { padding: .3em; }
.validateTips { border: 1px solid transparent; padding: 0.3em; }
style>
<script>
$(function() {
var dialog, form,
// From http://www.whatwg.org/specs/web-apps/current-work/multipage/states-of-the-type-attribute.html#e-mail-state-%28type=email%29
emailRegex = /^[a-zA-Z0-9.!#$%&'*+\/=?^_`{|}~-]+@[a-zA-Z0-9](?:[a-zA-Z0-9-]{0,61}[a-zA-Z0-9])?(?:\.[a-zA-Z0-9](?:[a-zA-Z0-9-]{0,61}[a-zA-Z0-9])?)*$/,
name = $( "#name" ),
email = $( "#email" ),
password = $( "#password" ),
allFields = $( [] ).add( name ).add( email ).add( password ),
tips = $( ".validateTips" );
function updateTips( t ) {
tips
.text( t )
.addClass( "ui-state-highlight" );
setTimeout(function() {
tips.removeClass( "ui-state-highlight", 1500 );
}, 500 );
}
function checkLength( o, n, min, max ) {
if ( o.val().length > max || o.val().length < min ) {
o.addClass( "ui-state-error" );
updateTips( "Length of " + n + " must be between " +
min + " and " + max + "." );
return false;
} else {
return true;
}
}
function checkRegexp( o, regexp, n ) {
if ( !( regexp.test( o.val() ) ) ) {
o.addClass( "ui-state-error" );
updateTips( n );
return false;
} else {
return true;
}
}
function addUser() {
var valid = true;
allFields.removeClass( "ui-state-error" );
valid = valid && checkLength( name, "username", 3, 16 );
valid = valid && checkLength( email, "email", 6, 80 );
valid = valid && checkLength( password, "password", 5, 16 );
valid = valid && checkRegexp( name, /^[a-z]([0-9a-z_\s])+$/i, "Username may consist of a-z, 0-9, underscores, spaces and must begin with a letter." );
valid = valid && checkRegexp( email, emailRegex, "eg. ui@jquery.com" );
valid = valid && checkRegexp( password, /^([0-9a-zA-Z])+$/, "Password field only allow : a-z 0-9" );
if ( valid ) {
$( "#users tbody" ).append( "" +
"" + name.val() + " " +
"" + email.val() + " " +
"" + password.val() + " " +
" " );
dialog.dialog( "close" );
}
return valid;
}
dialog = $( "#dialog-form" ).dialog({
autoOpen: false,
height: 400,
width: 350,
modal: true,
buttons: {
"Create an account": addUser,
Cancel: function() {
dialog.dialog( "close" );
}
},
close: function() {
form[ 0 ].reset();
allFields.removeClass( "ui-state-error" );
}
});
form = dialog.find( "form" ).on( "submit", function( event ) {
event.preventDefault();
addUser();
});
$( "#create-user" ).button().on( "click", function() {
dialog.dialog( "open" );
});
});
script>
head>
<body>
<div id="dialog-form" title="Create new user">
<p class="validateTips">All form fields are required.p>
<form>
<fieldset>
<label for="name">Namelabel>
<input type="text" name="name" id="name" value="Jane Smith" class="text ui-widget-content ui-corner-all">
<label for="email">Emaillabel>
<input type="text" name="email" id="email" value="jane@smith.com" class="text ui-widget-content ui-corner-all">
<label for="password">Passwordlabel>
<input type="password" name="password" id="password" value="xxxxxxx" class="text ui-widget-content ui-corner-all">
<input type="submit" tabindex="-1" style="position:absolute; top:-1000px">
fieldset>
form>
div>
<div id="users-contain" class="ui-widget">
<h1>Existing Users:h1>
<table id="users" class="ui-widget ui-widget-content">
<thead>
<tr class="ui-widget-header ">
<th>Nameth>
<th>Emailth>
<th>Passwordth>
tr>
thead>
<tbody>
<tr>
<td>John Doetd>
<td>john.doe@example.comtd>
<td>johndoe1td>
tr>
tbody>
table>
div>
<button id="create-user">Create new userbutton>
<div class="demo-description">
<p>Use a modal dialog to require that the user enter data during a multi-step process. Embed form markup in the content area, set the <code>modalcode> option to true, and specify primary and secondary user actions with the <code>buttonscode> option.p>
div>
body>
html>
這個是帶請求功能的對話框,代碼很嚴謹
var , form,
= /^[a-zA-Z0-9.!#$%&'*+\/=?^_`{|}~-]+@[a-zA-Z0-9](?:[a-zA-Z0-9-]{0,61}[a-zA-Z0-9])?(?:\.[a-zA-Z0-9](?:[a-zA-Z0-9-]{0,61}[a-zA-Z0-9])?)*$/,
name = $( "#name" ),
email = $( "#email" ),
= $( "#" ),
= $( [] ).add( name ).add( email ).add( ),
tips = $( "." );
定義元素變量,要用到的驗證, = $( [] ).add( name ).add( email ).add( ),這個用來把要用到的變量加到集合里面,用來添加和刪除css樣式,后面會用到的,很巧妙,$( [] )這個寫法可以把多個元素添加到一個集合中。
( t ) {
tips
.text( t )
.( "ui-state-" );
(() {
tips.( "ui-state-", 1500 );
}, 500 );
}
給元素添加文字和css樣式,并且在500毫秒內移除這個樣式,不明白.( "ui-state-", 1500 )后面一個參數1500是什么意思
( o, n, min, max ) {
if ( o.val(). > max || o.val(). < min ) {
o.( "ui-state-error" );
( " of " + n + " must be " +
min + " and " + max + "." );
false;
} else {
true;
}
}
檢查輸入文字的長短,4個參數分別是元素本身,元素名稱,最小長度,最大長度。
( o, , n ) {
if ( !( .test( o.val() ) ) ) {
o.( "ui-state-error" );
( n );
false;
} else {
true;
}
}
用正則表達式檢查元素是否符合規則模態對話框是什么時候實例的對話框,3個參數,元素本身,正則表達式,錯誤提示。
() {
var valid = true;
.( "ui-state-error" );
valid = valid && ( name, "", 3, 16 );
valid = valid && ( email, "email", 6, 80 );
valid = valid && ( , "", 5, 16 );
valid = valid && ( name, /^[a-z]([0-9a-z_\s])+$/i, " may of a-z, 0-9, , and must begin with a ." );
valid = valid && ( email, , "eg. " );
valid = valid && ( , /^([0-9a-zA-Z])+$/, " field only allow : a-z 0-9" );
if ( valid ) {
$( "#users tbody" ).( "" +
"
" + name.val() + "
" +
"
" + email.val() + "
" +
"
" + .val() + "
" +
"
" );
.( "close" );
}
valid;
}
添加用戶的方法,驗證方法valid = valid && 這個用的很巧妙,連續利用了&&操作,這里的寫法非常的靈活也很巧妙。在這里可以實現具體的功能,也可以在form里面添加,form到具體頁面中操作。
= $( "#-form" ).({
: false,
: 400,
width: 350,
modal: true,
: {
" an ": ,
: () {
.( "close" );
}
},
close: () {
form[ 0 ].reset();
.( "ui-state-error" );
}
});
這里才是最主要的功能,一個定義一個對話框,其中有個2個按鈕,一個是添加一個賬號,訪問函數,一個是取消,直接定義關閉對話框,最后還定義了默認的關閉功能,form中清除元素的值,清除錯誤提示。
form = .find( "form" ).on( "", ( event ) {
event.();
();
});
定義form,其實就是頁面中的form,還定義了提交時請求動作,首先取消默認事件,然后執行。
$( "#-user" ).().on( "click", () {
.( "open" );
});
給添加用戶按鈕綁定事件,這里綁定事件沒有直接.click,也沒有l(wèi)ive,也沒有,on是官方推薦的一個綁定函數方法。注意這里不是頁面加載的時候就顯示對話框,而是點擊添加賬號的時候彈出這個對話框,所以要先定義這個對話框“ = $( "#-form" ).({”,點擊添加按鈕的時候彈出對話框“.( "open" );”。
頁面截圖如下圖4
圖4
點擊添加用戶彈出對話框如圖5
圖5
元素驗證失敗時截圖如圖6
圖6
這個例子很經典!
d.帶動畫功能的對話框
關鍵代碼如下:
$(function() {
$( "#dialog" ).dialog({
autoOpen: false,
show: {
effect: "blind",
duration: 1000
},
hide: {
effect: "explode",
duration: 1000
}
});
$( "#opener" ).click(function() {
$( "#dialog" ).dialog( "open" );
});
});
定義顯示和影藏效果,: "blind":打開時時百葉窗效果,從上到下顯示,: ""關閉時是爆發,碎片效果。
百葉窗效果如下圖7
圖7
爆炸效果如圖8
圖8
同上,注意這里不是頁面加載的時候就顯示對話框,而是點擊添加賬號的時候彈出這個對話框,所以要先定義這個對話框“$( "#" ).({,”,點擊添加按鈕的時候彈出對話框“.( "open" );”
2.屬性,事件,方法
關于屬性,事件和方法內容很多,可以查看中文文檔
